Roller Crusher 700

Power 5.5 kw/7.5 HP,3 phase,430 V AC,50Hz
Applications fine grinding
Field of application agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology / metallurgy, medicine / pharmaceuticals
Feed material soft, medium-hard, brittle, fibrous
Size reduction principle impact, Friction
Material feed size* < 10 mm
Final fineness* < < 1 mm
Feed Hopper Opening * < 150mmx120mm
Roll Diameter   260mm (Pleated)
Rolls Width    150mm
Rolls Speed  150 -200 ( Optional Programmable)



Know More
Categories: ,

Description

Eloquent labaratory roll Crusher (or Roller Crusher) is used for middle crushing and fine crushing of all kinds of ores and rocks under mid-hardness range.This will be used in several industry liike mine, chemical industry, cement, building materials and other industrial sections.

APPLICATION EXAMPLES

  • Coal: clean coal, lignite (brown coal), bituminous, sub-bituminous and Anthracite
  • Ash: ash temperatures up to 350 deg. C
  • Coke: petroleum coke, metallurgical coke, green or calcined
  • Glass: glass cullet
  • Fertilizer and potash: MAP, DAP, potash ore and flake, among others
  • Salts:rock salt, solar salt, KCl, NaCl
  • Lime:burnt lime, Ag  lime, hydrated lime
  • Friable materials: ash, boiler slag, nuts and nut shells

PRODUCT ADVANTAGES

  • Solid structure, low noise and efficient
  • Easy to install and no foundation;
  • The pressure and size  adjustment

FEATURES

  • Solid structure, low noise and efficient
  • Easy to install and no foundation;
  • The pressure and size  adjustment

FUNCTION PRINCIPLE

The crushing will be done under the action of roll surface friction by a two cylindrical rolls rotating in inward directions when material falls on top of the rollers. The space between the roller can be adjusted for different size ranges
